HX2T 100 HP Oil-Free High-Pressure Reciprocating Air Compressor
Introduction
Key Benefits
100% Oil-Free Compressed Air
High-Pressure Industrial Performance
Continuous Duty Operation
Heavy-Duty Industrial Construction
High Airflow Capacity
Low Maintenance Operation
WHY HX2T 100 HP Oil-Free Air Compressor?
Technical Specifications
| Specification | Details |
| Compressor Type | Oil-Free Reciprocating Air Compressor |
| Lubrication | 100% Oil-Free |
| Motor Power | 100 HP |
| Free Air Delivery | 400 CFM @ 15 kg/cm² |
| Free Air Delivery | 417 CFM @ 12 kg/cm² |
| Operating Pressure | 12 – 15 kg/cm² |
| Compressor Duty | Continuous Industrial Operation |
| Dimensions | 2755 × 1875 × 2125 mm |
| Weight | 2900 kg |
How Does the HX2T 100 HP Oil-Free Air Compressor Work?
The HX2T 100 HP uses advanced oil-free reciprocating technology to produce clean, high-pressure compressed air for demanding industrial operations.
Step 1 – Air Intake
Ambient air is drawn through a high-efficiency intake filter that removes dust and airborne contaminants.
Step 2 – High-Pressure Compression
Heavy-duty reciprocating pistons compress the filtered air to the required operating pressure.
Step 3 – Oil-Free Compression
The compression chamber operates without oil, ensuring completely clean compressed air with zero contamination.
Step 4 – Air Cooling
The compressed air passes through an efficient cooling system to maintain optimum operating temperatures and improve compressor performance.
Step 5 – Air Delivery
High-pressure, oil-free compressed air is delivered continuously to industrial equipment and critical production processes.
Why Choose HX2T 100 HP?
Designed for demanding industrial environments, the HX2T 100 HP delivers exceptional performance, clean compressed air, and long-term operational reliability.
100% Oil-Free Air
Ensures contamination-free compressed air for industries with strict air quality requirements.
High-Pressure Performance
Delivers operating pressures up to 15 kg/cm² for demanding industrial applications.
High Airflow Capacity
Supplies up to 417 CFM, supporting high-volume compressed air requirements.
Continuous Duty Operation
Built for reliable 24/7 performance in demanding production environments.
Heavy-Duty Construction
Industrial-grade components provide maximum durability and extended service life.
Low Maintenance
Oil-free technology minimizes maintenance requirements while reducing operating costs.
Get in touch with our experts to find the right OF oil-free screw compressor for your application.
Keep your production running with dependable oil-free compressed air designed for applications where air purity, reliability, and consistent performance matter. The PX series delivers clean air without the risk of oil contamination, helping protect your processes, products, and equipment while supporting efficient day-to-day operations.
Industrial Applications
PET Bottle Manufacturing
Pharmaceutical Manufacturing
Chemical Processing
Food & Beverage Processing
Electronics Manufacturing
Heavy Industrial Manufacturing
Frequently Asked Questions
What industries is the HX2T 100 HP suitable for?
Can the HX2T 100 HP operate continuously?
Why choose an oil-free high-pressure air compressor?
What maintenance does the HX2T 100 HP require?
Can the HX2T 100 HP be integrated into an existing compressed air system?
Does Atcorp provide installation and after-sales support?
