HX1T 20 NP Oil-Free Reciprocating Air Compressor
Introduction
Key Benefits
100% Oil-Free Compressed Air
Reliable Medium-Pressure Performance
Continuous Industrial Duty
Precision Air Delivery
Energy-Efficient Operation
Durable Industrial Construction
WHY HX1T 20 NP Oil-Free Air Compressor?
Technical Specifications
| Specification | Details |
| Compressor Type | Oil-Free Reciprocating Air Compressor |
| Lubrication | 100% Oil-Free |
| Motor Power | 20 HP |
| Free Air Delivery | 70 CFM @ 9 kg/cm² |
| Free Air Delivery | 86 CFM @ 7 kg/cm² |
| Operating Pressure | 7 – 9 kg/cm² |
| Compressor Duty | Continuous Industrial Operation |
| Dimensions | 2540 × 1005 × 2000 mm |
| Weight | 1290 kg |
How Does the HX1T 20 NP Oil-Free Air Compressor Work?
The HX1T 20 NP uses oil-free reciprocating technology to produce clean, medium-pressure compressed air for precision industrial applications.
Step 1 – Air Intake
Ambient air enters through a high-efficiency intake filter to remove dust and airborne contaminants.
Step 2 – Air Compression
The reciprocating piston compresses the filtered air to the required medium operating pressure.
Step 3 – Oil-Free Compression
The compression chamber operates without oil, ensuring completely clean compressed air with zero contamination.
Step 4 – Air Cooling
The compressed air passes through an efficient cooling system to maintain stable operating temperatures and improve performance.
Step 5 – Air Delivery
Clean, medium-pressure compressed air is delivered continuously to industrial equipment and precision manufacturing processes.
Why Choose HX1T 20 NP?
Designed for precision industries, the HX1T 20 NP delivers dependable medium-pressure performance while ensuring the highest standards of compressed air quality.
100% Oil-Free Air
Provides clean compressed air with zero risk of oil contamination.
Optimized Medium Pressure
Delivers up to 9 kg/cm² pressure for demanding industrial applications.
Continuous Duty Performance
Built for reliable operation in continuous manufacturing environments.
Precision Air Supply
Ensures stable and consistent airflow for sensitive equipment and production processes.
Heavy-Duty Construction
Engineered with durable industrial components for long-lasting performance.
Low Maintenance
Oil-free technology reduces maintenance requirements and lowers operating costs.
Get in touch with our experts to find the right OF oil-free screw compressor for your application.
Keep your production running with dependable oil-free compressed air designed for applications where air purity, reliability, and consistent performance matter. The PX series delivers clean air without the risk of oil contamination, helping protect your processes, products, and equipment while supporting efficient day-to-day operations.
Industrial Applications
Food & Beverage Processing
Pharmaceutical Manufacturing
Electronics Manufacturing
Packaging Industries
Laboratories & Research Facilities
Precision Manufacturing
Frequently Asked Questions
What makes the HX1T 20 NP suitable for precision industries?
Can the HX1T 20 NP operate continuously?
Which industries commonly use the HX1T 20 NP?
What are the advantages of an oil-free compressor?
What maintenance does the HX1T 20 NP require?
Does Atcorp provide installation and after-sales support?
