CPF 180 - 340 HP Fixed Speed Oil-Lubricated Screw Air Compressors

The CPF 180–340 HP Series is designed for very large-capacity industrial operations requiring high-volume, reliable compressed air. With robust gear-driven technology, flexible pressure options, and heavy-duty construction, it delivers consistent performance for demanding production environments.
Download Brochure
Request A Quote

Introduction

Built for large-scale manufacturing and process industries, the CPF 180–340 HP Series combines high airflow capacity with dependable gear-driven performance. Available across multiple motor sizes and pressure configurations, it provides a scalable compressed air solution for continuous industrial operations where reliability, output, and efficiency are critical.

Key Benefits

Very Large Airflow Capacity
Wide Pressure Range
Robust Industrial Construction
Heavy-Duty Gear Drive
Continuous Industrial Performance
Scalable Capacity Options

WHY CPF 180 - 340 HP Fixed Speed Oil-Lubricated Screw Air Compressors?

The CPF Series is engineered for industries with substantial compressed air requirements and demanding production schedules. Its high-capacity rotary screw technology, gear-driven transmission, and flexible pressure range provide dependable air delivery while supporting efficient and reliable plant operations.
Specification CPF 180 HP CPF 220 HP CPF 270 HP CPF 340 HP
Compressor Type Rotary Screw Air Compressor Rotary Screw Air Compressor Rotary Screw Air Compressor Rotary Screw Air Compressor
Lubrication Oil-Lubricated / Oil-Injected Oil-Lubricated / Oil-Injected Oil-Lubricated / Oil-Injected Oil-Lubricated / Oil-Injected
Motor Power 180 HP 220 HP 270 HP 340 HP
Drive Gear Gear Gear Gear
Pressure 7 / 8 / 10 / 13 bar 7 / 8 / 10 / 13 bar 7 / 8 / 10 / 13 bar 7 / 8 / 10 / 13 bar
Mounting Floor Mounted Floor Mounted Floor Mounted Floor Mounted
Size 2 2 3 3
FAD @ 7 bar 912 CFM 1,043 CFM 1,285 CFM 1,599 CFM
FAD @ 8 bar 869 CFM 992 CFM 1,200 CFM 1,511 CFM
FAD @ 10 bar 770 CFM 905 CFM 1,094 CFM 1,363 CFM
FAD @ 13 bar 642 CFM 774 CFM — —
Noise Level 79 dB(A) 78 dB(A) 80 dB(A) 80 dB(A)
Air Outlet G2 DN80 DN100 DN100

The CPF Series uses rotary screw technology to continuously compress and deliver high volumes of compressed air for large-scale industrial applications.



Step 1 – Air Intake

Ambient air enters through the intake system and passes through filtration before compression.



Step 2 – Air Compression

Precision rotary screw elements continuously compress the filtered air to the required operating pressure.



Step 3 – Oil Lubrication

Oil cools, lubricates, and seals the compression process, supporting efficient operation and protecting internal components.



Step 4 – Oil Separation

The compressed air passes through the separation system before entering the air delivery circuit.



Step 5 – Air Delivery

High-volume compressed air is continuously supplied to production machinery, pneumatic systems, and plant utilities.

Built for very large industrial compressed air requirements, the CPF Series delivers exceptional capacity, robust performance, and pressure flexibility.



Very High Airflow

Delivers up to 1,599 CFM at 7 bar in the 340 HP configuration.



Gear-Driven Technology

Provides dependable power transmission for high-capacity industrial compressor operation.



Wide Pressure Range

Supports operating pressures from 7 to 13 bar across the series.



Multiple Capacity Options

Available from 180 to 340 HP, allowing businesses to select capacity according to plant requirements.



Heavy-Duty Construction

Engineered for demanding industrial environments and continuous production operations.



Reliable Air Delivery

Provides consistent compressed air to support large-scale production and plant utilities.

Industrial Applications

The CPF 180–340 HP Series is designed for large-scale industries requiring high-volume compressed air for continuous production and demanding process applications.
Steel Plants
Provides high-capacity compressed air for pneumatic systems, automation, and plant utilities.
Power Plants
Supports pneumatic equipment, instrumentation, and critical plant utility applications.
Oil & Gas
Delivers reliable compressed air for demanding industrial operations and pneumatic systems.
Cement Plants

Supports material handling, automation, pneumatic equipment, and continuous plant operations.

Automotive Manufacturing
Provides high-volume compressed air for production lines, automation, and pneumatic machinery.

Frequently Asked Questions

Find answers to common questions about the CPF 180–340 HP Fixed Speed Oil-Lubricated Screw Air Compressors, including capacity, pressure, applications, and maintenance.
The CPF Series covered here is available in 180, 220, 270, and 340 HP configurations, providing multiple capacity options for large-scale industrial compressed air requirements.
The CPF Series supports operating pressure options of 7, 8, 10, and 13 bar, depending on the selected model and configuration.
The 340 HP CPF model delivers up to 1,599 CFM at 7 bar, while the 180 HP model provides up to 912 CFM at 7 bar.
Yes. The CPF Series is designed for demanding industrial environments requiring dependable compressed air across continuous production operations.
The CPF 180–340 HP models use a gear-driven transmission, designed to provide reliable power transfer for high-capacity compressor applications.
The series is suitable for steel, power, oil & gas, cement, automotive, pharmaceutical, chemical, glass, and other large-scale industrial applications.
Yes. Atcorp provides preventive maintenance, Annual Maintenance Contracts (AMC), genuine spare parts, and technical support to help maintain compressor efficiency, reliability, and plant uptime.
